Drive kit for sliding gates up to 400 kg / 7 m NICE Robus RB400 (E)
TOP| Product availability: | In stock | We normally dispatch goods within 24 hours. |
|---|
in stock
€700.65 including VAT
| Weight |
|---|
| 16 kg |
Description of Drive kit for sliding gates up to 400 kg / 7 m NICE Robus RB400 (E)
The NICE RB400 drive has been replaced by a newer model NICE RBS400. See the benefits of the newer NICE RBS400 and RBS600 models.
The NICE RB400 (E) kit will be replaced by the NICE RBS400 (E) kit.
NICE Robus RB400 gate operator is designed for sliding gates weighing up to 400 kg and a passage width of up to 7 m. It has an electromechanical limit switch. The operator is non-reversible. Detailed technical specifications ». Download the manual ».
| The set includes: | NICE-RB400-E | |||
|---|---|---|---|---|
 |
1 × | NICE Robus RB400 gate operator | NICE-RB400 | |
|
NICE Robus RB400 electromechanical gate operator with an RBA3R10 control unit, for gates weighing up to 400 kg and with a leaf length of up to 7 m. |
Details  |
|||
 |
1 × | NICE MYGO4 remote control | NICE-MYGO4 | |
|
Four-button remote control for operating an automatic gate. You can use it to control four devices or send four different commands to one device. Compatible with all NICE operators using O-Code rolling code technology (the 72-bit code allows 4.7 quadrillion combinations, making it virtually impossible to compromise) and an LED signal transmission indicator. |
Details |
|||
 |
1 × | Pair of NICE Era Photocell EPMB photocells | NICE-EPMB | |
|
Safety photocells are installed on either side of the passageway. They emit an infrared beam which, when interrupted by a vehicle or pedestrian, for example, sends a signal to the operator to stop the gate or prevent it from opening. |
Details |
|||
 |
1 × | NICE OXIBD receiver | NICE-OXIBD | |
|
Receiver for radio signals from remote controls. |
Details |
|||
 |
2 × | Release key | ||
|
In the event of a power failure, it disengages the operator's drive gear so the gate can be moved manually by pushing or pulling. |
||||
 |
1 × | NICE Robus RB400 installation manual | ||
|
Installation manual with illustrative wiring diagrams and instructions for programming and pairing remote controls. |
Download |
|||
 |
2 × | Limit stop (left + right) | ||
|
The operator limit stops are mounted on the rack and define the gate's travel length. |
||||
| 1 × | Installation accessories | |||
|
Operator installation components, height adjustment screws, mounting plate, anchor caps. |
||||
 |
4 m | Gear rack with metal reinforcement | LZ-1-4 | |
|
The sliding gate, with the gear rack fixed in place, is moved by the operator's pinion engaging with the rack. |
Details |
|||
(Is this operator right for me?)
Compare with other operator kits:
| « Lower-powered kit | Alternative kit | More powerful kit » |
|---|---|---|
|
No. |
|
|
Drive features NICE ROBUS RB400
The drive is compact, safe, practical, and ideal for both residential and commercial use. Impact-resistant cover, aluminium-alloy body with an epoxy coating.
The drive is suitable for automating sliding gates weighing up to 400 kg, with a gate leaf length of up to 7 m. These values apply under the conditions specified by the manufacturer, such as weather conditions, temperature variations, gate rigidity and, above all, ease of gate movement. These conditions cannot always be achieved or controlled, so we recommend using the NICE Robus RB400 drive with gates operating at 80% of these limits. See the Choosing a drive chapter for more information.
Very user- friendly technology BlueBUS allows to power and control up to 7 pairs of photocells using a two-core cable.
The temperature sensor adjusts the drive's pulling force depending on the weather conditions. The drive also includes a thermal fuse.
Adjustable speed,, force and pause time for automatic closing of the drive, and much more; see Programming.
Diagnostics using warning beacon.
The gearwheel module 4 is compatible with the rack available in our range.
Robus 400 drive functions "The slave unit" ensures automatic synchronisation of two motors. This means that two sliding gates moving towards each other can be automated.
The NICE Robus RB400 is an electromechanical drive suitable for the climate in Slovakia and compliant with all European safety standards.
The ROBUS RB400 in pictures
| release | control unit | wiring diagram |
|---|---|---|
 |
 |
 |
| Instructions for releasing > |
Programming the drive > |
Detailed wiring diagram > |
For a detailed wiring diagram and further technical information, see on the NICE Robus RB400 drive's own page, or in the manual..
Drive specifications NICE ROBUS RB400
| Speed | 0.18 - 0.34 m/s |
|---|---|
| Power supply | 230V, 50/60Hz |
| Power consumption | 330W |
| Torque | 6Nm |
| Max. torque | 12Nm |
| Max. gate weight | 400kg |
| Ingress protection rating | IP 44 |
| Operating temperature | -20°C to +50°C |
| Insulation class | 1 |
| Gear module | 4 |
Full technical specifications on the NICE Robus RB400 drive's own page.
Accessories compatible with the NICE Robus RB400 drive
We also recommend purchasing compatible optional accessories for the drive, or choosing one of the ready-assembled discounted sets:
| What | Why | Type |
|---|---|---|
| Beacon | The beacon flashes to indicate gate movement—ideal for exits with poor visibility. It also has a built-in antenna for greater remote-control range. | - LED beacon with antenna ELDC - multifunction light WLT - wireless solar LED beacon LLW |
| Photocells | They detect obstacles while closing and stop the movement, preventing the gate from hitting cars or people. | - Era Photocell Medium EPMB - Era Photocell Large EPLB - Era Photocell Slim EPSB - wireless FT210B - wireless EPMOW - solar-powered PHW |
| Transmitter | For remote gate control. | - Era One ON2E, ON3EBD, ON3ELR, ON4E, ON9E - Era Flor Flo2RE, Flo4RE - FloR Flo2R-s, Flo4R-s - Inti INTI2, INTI2Y, INTI2L, INTI2B, INTI2R, INTI2G |
| Receiver | Required for remote gate control. | - OXI - OXIBD - OXILR - Wi-Fi receiver IT4WIFI - GSM receiver GSM LITE3+, GSM SMART3, GSM PROFI3 |
| Antenna | For improved remote control range. | - integrated into the warning light ELDC - standalone antenna ABFKIT |
| Keypad | Useful if you forget your remote, if many vehicles or people visit, or if you don't want to give everyone a remote or open the gate manually. | - wireless EDSWG - wired EDSB |
| Key switch | Control the gate with a key using a switch wired to the drive from any convenient location. | - surface-mounted, with standard cylinder EKS - surface-mounted, with European cylinder EKSEU - flush-mounted, with standard cylinder EKSI - flush-mounted, with European cylinder EKSIEU |
| Card Readers | Control the drives by presenting a card or key fob to the card reader. | - ERA Transponder Reader ETPB |
| Gearing | Required for the drive's automation; without a rack, the drive cannot move the gate. | - nylon, steel-reinforced, 33 cm LZ-1 - nylon, steel-reinforced, 1 m LZ-10 - nylon, steel-reinforced, reversed, 1 m LZ-15 - steel 30x8mm, 1m LZ-3 - steel 30x12mm, 1m LZ-5 - stainless steel 30x10mm, 1m LZ-7 |
| Backup power supply | Keeps the gate operating in the event of a power failure. | - backup battery PS124 - solar power supply SYKCE |
