Drive kit for sliding gates up to 400 kg/7 m NICE Robus RB400 (C)
| Product availability: | In stock | We normally dispatch goods within 24 hours. |
|---|
in stock
€651.91 including VAT
| Weight |
|---|
| 9,30 kg |
Description of Drive kit for sliding gates up to 400 kg/7 m NICE Robus RB400 (C)
The NICE RB400 drive has been replaced by a newer model NICE RBS400. See the benefits of the newer NICE RBS400 and RBS600 models.
The NICE RB400 (C) kit will be replaced by the NICE RBS400 (C) kit.
NICE Robus RB400 gate operator is designed for sliding gates weighing up to 400 kg and a clear opening width of up to 7 m. It has an electromechanical limit switch. The operator is non-reversible. Detailed technical specifications ». Download the manual ».
| The kit includes: | NICE-RB400-C | |||
|---|---|---|---|---|
 |
1 × | NICE Robus RB400 operator | NICE-RB400 | |
|
NICE Robus RB400 electromechanical operator with RBA3R10 control unit, for gates with a total weight of up to 400 kg and a leaf length of up to 7 m. |
Details  |
|||
 |
1 × | NICE MYGO4 remote control | NICE-MYGO4 | |
|
Four-button remote control for operating an automatic gate remotely. You can use it to control four devices or send four different commands to one device. Compatible with all NICE operators using O-Code rolling-code technology (the 72-bit code allows 4.7 quadrillion combinations, making it virtually impossible to misuse) and an LED indicator for the transmitted signal. |
Details |
|||
 |
1 × | Pair of NICE Era Photocell EPMB photocells | NICE-EPMB | |
|
Safety photocells are installed on either side of the gate opening. They create an infrared beam that, when interrupted by a vehicle or pedestrian, for example, sends a signal to the operator to stop the gate or prevent it from opening. |
Details |
|||
 |
1 × | NICE OXIBD receiver | NICE-OXIBD | |
|
Receiver for radio signals from remote controls. |
Details |
|||
 |
2 × | Release key | ||
|
In the event of a power failure, it disengages the operator's drive gear so the gate can be moved manually by pushing or pulling. |
||||
 |
1 × | NICE Robus RB400 installation manual | ||
|
Installation manual for successful installation, with illustrative wiring diagrams and instructions for programming and pairing remote controls. |
Download |
|||
 |
2 × | Limit stop (left + right) | ||
|
The operator's limit stops are mounted on the toothed rack and set the gate's travel distance. |
||||
| 1 × | Installation accessories | |||
|
Operator installation components, height-adjustment screws, mounting plate, anchor caps. |
||||
(Is this operator right for me?)
Compare it with other operator kits:
| « Lower-powered kit | Alternative kit | Higher-powered kit » |
|---|---|---|
|
No. |
|
|
Operator features NICE ROBUS RB400
The operator is compact, safe and practical, and ideal for both residential and commercial use. Impact-resistant cover, aluminium-alloy housing with an epoxy coating.
The operator is suitable for automating sliding gates weighing up to 400 kg with a leaf length of up to 7 m. These figures apply under the conditions specified by the manufacturer, including weather conditions, temperature variations, gate rigidity and, above all, smooth gate movement. These conditions cannot always be achieved or controlled, so we recommend using the NICE Robus RB400 operator ideally with gates in the category 80% of these values. See the chapter Choosing a drive for more information.
Very user- friendly technology BlueBUS allows to power and control up to 7 pairs of photocells using a two-core cable.
Temperature sensor adjusts the drive's pulling force depending on the weather conditions. The drive also includes a thermal fuse.
Adjustable speed, force and pause time for automatic drive closing and much more; see Programming.
Diagnostics using warning beacon.
The pinion module 4 is compatible with the rack in our range.
Robus 400 drive features "Slave unit" ensures automatic synchronisation of two motors. This means that two sliding gates moving towards each other can be automated.
The NICE Robus RB400 is an electromechanical drive suited to Slovakia's climate and meets all European safety standards.
The ROBUS RB400 in pictures
| release | control unit | wiring diagram |
|---|---|---|
 |
 |
 |
| Instructions for releasing > |
Programming the drive > |
Detailed wiring diagram > |
For the detailed wiring diagram and more technical information, see on the NICE Robus RB400 drive's product page, or in the manual.
Drive technical specifications NICE ROBUS RB400
| Speed | 0.18 - 0.34 m/s |
|---|---|
| Power supply | 230V, 50/60Hz |
| Power consumption | 330W |
| Torque | 6Nm |
| Max. torque | 12Nm |
| Max. gate weight | 400kg |
| Protection rating | IP 44 |
| Operating temperature | -20°C to +50°C |
| Insulation class | 1 |
| Gear module | 4 |
Full technical specifications on the NICE Robus RB400 drive product page.
Accessories compatible with the NICE Robus RB400 drive
We also recommend purchasing compatible optional accessories for the drive, or choosing one of our pre-assembled discounted bundles:
| What | Why | Type |
|---|---|---|
| Beacon | The beacon flashes to signal gate movement—ideal for exits with limited visibility. It also has a built-in antenna for greater remote-control range. | - LED beacon with antenna ELDC - multifunction light WLT - wireless solar LED beacon LLW |
| Photocells | They detect obstacles and stop the gate as it closes, preventing it from hitting cars or people. | - Era Photocell Medium EPMB - Era Photocell Large EPLB - Era Photocell Slim EPSB - wireless FT210B - wireless EPMOW - solar-powered PHW |
| Transmitter | For remote gate control. | - Era One ON2E, ON3EBD, ON3ELR, ON4E, ON9E - Era Flor Flo2RE, Flo4RE - FloR Flo2R-s, Flo4R-s - Inti INTI2, INTI2Y, INTI2L, INTI2B, INTI2R, INTI2G |
| Receiver | Required for remote gate control. | - OXI - OXIBD - OXILR - Wi-Fi receiver IT4WIFI - GSM receiver GSM LITE3+, GSM SMART3, GSM PROFI3 |
| Antenna | For improved remote-control range. | - integrated into the warning light ELDC - stand-alone antenna ABFKIT |
| Keypad | Useful if you forget your remote, if many vehicles or people need access, or if you don’t want to give everyone a remote or open the gate manually. | - wireless EDSWG - wired EDSB |
| Key switch | Operate the gate with a key using a switch connected to the drive by cable at a location of your choice. | - surface-mounted, with a standard cylinder EKS - surface-mounted, with a European cylinder EKSEU - flush-mounted, with a standard cylinder EKSI - flush-mounted, with a European cylinder EKSIEU |
| Card readers | Operate the drive by presenting a card or key fob to the card reader. | - ERA Transponder Reader ETPB |
| Gear rack | Essential for automating the drive—the rack is what allows the drive to move the gate. | - nylon, with steel reinforcement, 33 cm LZ-1 - nylon, with steel reinforcement, 1 m LZ-10 - nylon, with steel reinforcement, reverse, 1 m LZ-15 - steel, 30x8mm, 1 m LZ-3 - steel, 30x12mm, 1 m LZ-5 - stainless steel, 30x10mm, 1 m LZ-7 |
| Backup power supply | In the event of a power outage, it keeps the gate running. | - backup battery PS124 - solar power supply SYKCE |
Manuals and documents for download
