NICE Toona 5024 drive kit for double-leaf gates – one leaf 5 m/500 kg
| Product availability: | In stock | We normally dispatch goods within 24 hours. |
|---|
In stock
€1,332.94 including VAT
| Weight |
|---|
| 22 kg |
Description of NICE Toona 5024 drive kit for double-leaf gates – one leaf 5 m/500 kg
Drive kit NICE Toona 5 TO5024 is designed for automation of swing gates up to gate leaf length 5 m and weight up to 500 kg. The operator is based on 24V and has PLA13 mechanical opening stop. The operator is non-reversible. The Toona drives are currently top of the range for automation of swing gates in both private and industrial settings. The entire Toona is reliable and quiet. Detailed technical specifications ». Download the manual ».
| Set NICE-TO5024-B2 contains: | ||||
|---|---|---|---|---|
|
2 × | NICE Toona 5 TO5024 Drive | NICE-TO5024 | |
|
NICE Toona TO5024 electromechanical gate operator for gate leaves weighing up to 500 kg and measuring up to 5 m in length.
|
Details
|
|||
|
1 × | Control unit for 24 V swing gate operators, MC824HR30 | NICE-MC824HR30 | |
|
The control unit in a designer enclosure, containing the MCA1R30 control board to which the drives and accessories are connected, is part of the automation system. |
Details
|
|||
|
1 × | NICE MYGO4 - four-channel remote control | NICE-MYGO4 | |
|
NICE MYGO4 - four-channel remote control, rolling code, 433.92 MHz |
Details
|
|||
|
1 × | NICE OXIBD remote control receiver | NICE-OXIBD | |
|
Radio signal receiver for remote controls. Supports two-way communication with selected remote control models. Range of up to 200m with an antenna. |
Details
|
|||
|
1 × | NICE Toona 5 TO5024 Installation Manual |
Download
|
|
|
Installation manual with illustrated wiring diagrams and instructions for programming and pairing remote controls. |
||||
2 pcs. release keys
front + rear bracket
Mounting accessories
(Is this drive right for me?)
Compare with other drives:
| « Weaker kit | Alternative kit | Stronger kit » | ||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
230V NICE Toona drives:
Quote and delivery available on request. |
|
Drive features NICE Toona TO5024
The drive is made from a two-piece die-cast aluminium housing with a polyester coating that resists the effects of weather. All internal moving parts are made of steel, light alloys and technopolymers. The lead screw nut is made of bronze to ensure high strength and quiet operation. The start capacitor is located inside the drive to make installation as simple as possible. The drives are dimensionally backward-compatible with the previous Moby and Pluto series from the Italian manufacturer NICE; all mounting dimensions and pin diameters are the same. The drive uses 24V, making it better suited to situations involving more frequent use than the 230V version. However, this 24V version is not suitable for windy conditions, especially with opaque, solid gate infill.
The drive has a magnetic encoder, which enables the Moonclever MC824HR30 control unit for the drive to determine the drive's position along its travel path. MC824HR30 control unit is equipped with the BlueBus, which allows simple programming, automatic detection of limit positions, automatic fault diagnostics, adjustment of the pause time in automatic closing mode, pedestrian opening, deceleration before the end positions, a dual obstacle-impact detection system, and emergency operation when using PS324 backup power supply, an input for all types of safety edges, and much more. To connect the PS324 , you need a CABLA11.
Accessories compatible with the drive NICE Toona 5 TO5024
We also recommend purchasing the following optional accessories compatible with the drive:
| What | Why | Type |
|---|---|---|
| Control unit |
Drive control electronics. |
|
| Flashing beacon | Flashes to indicate gate movement—useful at exits with limited visibility. Also includes an antenna for greater remote-control range. |
Alternatively, any flashing beacons with a 12V–24V supply from other manufacturers. |
| Photocells | They detect an obstacle while the gate is closing and stop its movement, preventing it from hitting a vehicle or a person. | |
| Transmitter | For remote control of the gate. | |
| Receiver |
For remote control of the gate. |
|
| Antenna | For better remote-control range. | |
| Keypad | If you forget your remote control, or have many vehicles/people and don't want to give each one a remote. | |
| Key switch | Control the gate with a key using a switch wired to the operator. | |
| Electric locks | Safety electric locks are synchronized with the operator via the control unit. When the operator receives a command, the electric lock is unlocked first, and only then does the gate begin to open. Once the gate has closed, the electric lock is secured again. Required for gate leaves over 3 m long. |
|
| Card readers | Operate the gate by presenting a card or key fob to the reader. |
|
| Backup power supply | Keeps the gate operating during a power outage. |
|
Manual for the NICE Toona 5 TO5024 operator and NICE Moonclever control unit Moonclever MC824H
Manual for the NICE Toona 5 TO5024 and NICE control unit Moonclever MC824H download here:
Manual for the NICE Toona 5 TO5024 operator
NICE Toona operator photo gallery
|
Installation example |
Installation example |
Installation example |
|
Installation example |
Installation example |
Operator with cover removed |
|
Comparison of Toona 4, 5, and 7 operators |
Operator unlocked |
Operator, underside |
Technical specifications
| Detailed technical specifications of NICE Toona 5 TO5024 operators |
