NICE Wingo 3524 drive kit for a double-leaf gate – one leaf 3.5 m/500 kg, with accessories
TOP| Product availability: | In stock | We normally dispatch goods within 24 hours. |
|---|
in stock
€860.01 including VAT
| Weight |
|---|
| 19 kg |
Description of NICE Wingo 3524 drive kit for a double-leaf gate – one leaf 3.5 m/500 kg, with accessories
Operator NICE Wingo WG3524 is designed for automating swing gates up to gate leaf length 3.5 m and weight up to 500 kg. The operator is based on 24V and has PLA13 mechanical opening stop. The operator is non-reversible. The Wingo operators offer good value for money for automating swing gates in residential and light industrial settings. The entire Wingo family is reliable and quiet. Detailed technical specifications ». Download the manual ». NICE Wingo WG3524 features a new control unit MC424LR30 which includes a control board MCA2R30 with a built-in receiver, The slot for an optional receiver has been retained, in case you want to use an older receiver with your remote controls already programmed.
| The kit includes: | NICE-WG3524BE2 | |||
|---|---|---|---|---|
 |
2 × | NICE Wingo WG3524 operator | NICE-WG3524 | |
|
NICE Wingo WG3524 electromechanical gate operator, suitable for gate leaves weighing up to 500 kg and measuring up to 3.5 m in length. |
Details | |||
 |
1 × | NICE MC424LR30 control unit | NICE-MC424LR30 | |
|
The Moonclever control unit in a designer enclosure includes a control board MCA2R30 with a built-in receiver, which connects the operators and accessories, is an essential part of the automation system. |
Details  |
|||
 |
1 × | NICE Era INTI2 remote control | NICE-INTI2 | |
|
Two-button remote control for operating your gate automatically from a distance. You can use it to control two devices or send two different commands to one device. |
Details |
|||
 |
1 × | Pair of NICE EPM photocells | NICE-EPM | |
|
NICE EPM outdoor safety photocells are installed opposite each other across the gate opening, or at any point where there is a risk of the gate hitting an obstacle. |
Details |
|||
 |
1 × | NICE ELDC LED beacon with antenna | NICE-ELDC | |
|
NICE LED flashing ELDC warning light, made of impact-resistant polycarbonate and featuring a built-in antenna for extended remote-control range (up to 150 m). |
Details |
|||
 |
2 × | Release key | ||
|
In the event of a power failure, it releases the operator so the gate can be moved manually by pushing or pulling. |
||||
 |
1 × | NICE Wingo WG3524 installation manual | ||
|
Installation manual with illustrated wiring diagrams and instructions for programming and pairing remote controls. |
Download |
|||
| 1 × | Installation accessories | |||
|
Operator installation components, front and rear brackets for welding, |
||||
(Is this operator right for me?)
Compare with other operators:
| « Lower-powered kit | Alternative operator | More powerful kit » | |||||
|---|---|---|---|---|---|---|---|
|
NICE Wingo WG2024 operator kit
|
230V NICE Wingo gate opener:
Quote and delivery available on request. |
NICE Toona 4 TO4024 gate opener kit
|
GATE OPENER FEATURES NICE WINGO WG3524
The gate opener is made from a two-piece die-cast aluminium housing with a polyester coating that resists weathering. All internal moving parts are made of steel, light alloys and technopolymers. The lead nut is made of bronze to ensure high strength and quiet operation. The start-up capacitor is housed inside the gate opener to make installation as simple as possible. The gate openers are dimensionally backward-compatible with the previous Moby and Pluto series from the Italian manufacturer NICE; all mounting dimensions and pin diameters are the same. The gate opener uses 24V, making it more suitable for situations involving more frequent use than the 230V version. version, but it is not suitable for windy locations, especially with solid, opaque gate infill.
Control unit MCA2R30 in the control cabinet MC424LR30 allows simple programming, automatic detection of limit positions, automatic fault diagnosis, adjustable pause time in automatic closing mode, pedestrian opening, slowing down before reaching the end positions, obstacle impact detection, and emergency operation when using the PS124 backup power supply, using the connecting cable CABLA11, input for all types of safety edges and much more.
ACCESSORIES COMPATIBLE WITH THE NICE WINGO WG3524 GATE OPENER
We also recommend purchasing these compatible optional accessories for the gate opener:
| What | Why | Type |
|---|---|---|
| Control unit | Gate opener control electronics. Includes a built-in control unit. Conventional wiring system. |
|
| Flashing beacon | Flashes to indicate gate movement—ideal for exits with poor visibility. Also includes an antenna for greater remote-control range. |
Alternatively, all flashing beacons with 12V–24V power supply from other manufacturers. |
| Photocells | Detect obstacles while the gate is closing and stop its movement, preventing it from hitting cars or people. | |
| Transmitter | For remote control of the gate. | |
| Receiver |
For remote gate control. In the control unit MCA2R30 the receiver is already built in. These additional receivers are optional accessories. |
|
| Antenna |
For improved remote-control range. |
|
| Keypad |
If you forget your remote control, or if many vehicles or people visit your property and you don't want to give everyone a remote or open the gate manually. |
|
| Key switch |
For operating the gate with a key using a switch connected to the operator by cable at any chosen location. |
|
| Card readers |
Operate the gate operator by presenting a card or key fob to the card reader. |
|
| Electric locks |
Safety electric locks are synchronized with the operator via the control unit. When an operator command is issued, the electric lock unlocks first, and only then does the gate begin to open. Likewise, after the gate closes, the electric lock engages. They are required for gate leaves longer than 3.5 m. |
|
| Backup power supply |
Backup power source. |
NICE WINGO WG3524 GATE OPERATOR MANUAL
NICE gate operator manual Wingo WG3524 download here:
NICE Wingo WG3524 gate operator manual
NICE Wingo gate operator photo gallery
|
Installation example |
Installation example |
Installation example |
|
Installation example |
Installation example |
Installation example |
|
Installation example
|
Operator unlocked |
Operator with cover removed |
|
Rear view from below |
Worm screw and mechanical internal stop |
Front view from below |
|
Rear view with cable connected |
Technical specifications
| Detailed technical specifications for NICE Wingo WG3524 operators > | Detailed technical specifications for the NICE Moonclever MC424LR30 control unit > |
