Sliding gate operator kit for gates up to 400 kg / 8 m NICE Road RD400 (X)
| Product availability: | In stock | We normally dispatch goods within 24 hours. |
|---|
In stock
€456.63 including VAT
| Weight |
|---|
| 10 kg |
Description of Sliding gate operator kit for gates up to 400 kg / 8 m NICE Road RD400 (X)
NICE Road RD400 operator is designed for sliding gates weighing up to 400 kg and a passage width up to 8 m (recommended maximum length 5m). It has an electromechanical stop switch. The operator is non-reversible. Detailed technical specifications ». Download the manual ».
| Set NICE-RD400-X contains: | ||||
|---|---|---|---|---|
|
1 × | NICE Road 400 Gate Opener | NICE-RD400-A | |
|
NICE electromechanical operator with RBA4R10 control unit and built-in receiver, suitable for gates weighing up to 400 kg.
|
Details
|
|||
|
2 × | NICE Era Flor FLO2RE Remote Control | NICE-FLO2RE | |
|
Two-button remote control for operating a gate automatically from a distance. You can use it to control two devices or send two different commands to one device. |
Details
|
|||
2 unlocking keys
End stops
(Is this drive right for me?)
Compare with other drives:
| « Weaker kit | Alternative kit | Stronger kit » |
|---|---|---|
|
No. |
|
|
Drive features NICE Road 400
The drive is compact, safe and practical, ideal for both residential and commercial use. Impact-resistant cover, aluminium alloy body with an epoxy coating.
The drive is suitable for automating a sliding gate weighing up to 400 kg, with a gate leaf length of up to 8 m. These figures apply under the conditions specified by the manufacturer, such as weather conditions, temperature variations, gate rigidity and, above all, smooth gate movement. These conditions cannot always be achieved or controlled, so we recommend using the NICE Road RD400 drive ideally with gates operating at 60% of these limits. See the Choosing a Drive chapter for more information.
The standard wiring allows you to power and control 2 pairs of photocells using a four-core cable.
The temperature sensor adjusts the drive's pulling force according to climatic conditions.
Adjustable speed,, force and pause time for automatic drive closing and more; see Programming.
Diagnostics using a warning beacon.
The gear wheel module 4 is compatible with the rack available in our range.
The NICE Road RD400 is an electromechanical drive suitable for Slovakia's climate and compliant with all European safety standards.
The NICE Road RD400 in pictures
| manual release | control unit | wiring diagram |
|---|---|---|
 |
 |
 |
| Instructions for manual release > |
Programming the drive > |
Detailed wiring diagram > |
You can find the detailed wiring diagram and further technical information on the NICE Road RD400 drive's own product page, or in the manual..
Note: if you do not use photocells, that's not a problem: the drive can operate without photocells, but you need to connect on the terminal block the terminals 1 and 5.
Drive technical specifications NICE Road RD400
| Speed | 0,25 m/s |
|---|---|
| Power supply | 230V, 50Hz |
| Power consumption | 210W |
| Torque | 12NM |
| Max. nominal torque | 5 |
| Max. gate weight | 400kg |
| Protection rating | IP 44 |
| Operating temperature | -20°C to +50°C |
| Insulation class | 1 |
| Gear module | 4 |
Complete technical specifications on the website NICE Road RD400 drive unit only.
Compatible accessories for the NICE Road RD400 drive unit
We also recommend purchasing compatible optional accessories for the drive unit, or choosing one of our pre-assembled discounted kits:
| What | Why | Type |
|---|---|---|
| Warning light | The warning light flashes to indicate that the gate is moving—ideal for exits with poor visibility. It also has a built-in antenna for greater remote-control range. | - LED warning light with antenna ELDC - multifunction LED light WLT |
| Photocells | When closing, they detect obstacles and stop the gate—preventing it from hitting cars or people. | - photocells with conventional wiring BF - Era Photocell Medium EPM - Era Photocell Large EPL - Era Photocell Slim EPS - wireless/conventional FT210 - Era Photocell Medium Antivandal EPMA |
| Transmitter | For remote control of the gate. | - Era One ON2E, ON3EBD, ON3ELR, ON4E, ON9E - Era Flor Flo2RE, Flo4RE - FloR Flo2R-s, Flo4R-s - Inti INTI2, INTI2Y, INTI2L, INTI2B, INTI2R, INTI2G |
| Receiver | For remote control of the gate. The Road 400 drive unit already has a built-in receiver. These additional receivers are optional extras. |
- Wi-Fi receiver IT4WIFI - GSM receiver GSM LITE3+, GSM SMART3, GSM PROFI3 |
| Antenna | For greater remote-control range. | - integrated into the warning light ELDC - standalone antenna ABFKIT |
| Keypad | Useful if you forget your remote, if many vehicles or people need access, or if you don't want to give everyone a remote or open the gate manually. | - wired EDS |
| Key switch | Operate the gate with a key using a switch connected to the drive unit by cable, wherever required. | - surface-mounted, with a standard cylinder EKS - surface-mounted, with a European cylinder EKSEU - flush-mounted, with a standard cylinder EKSI - flush-mounted, with a European cylinder EKSIEU |
| Card readers | Control the drives by holding a card or key fob against the card reader. | - ERA Transponder Reader ETP |
| Toothed racks | Required for the drive automation itself – without a rack, the drive has nothing to move the gate with. | - nylon, with steel reinforcement, 33 cm LZ-1 - nylon, with steel reinforcement, 1 m LZ-10 - nylon, with steel reinforcement, reverse version, 1 m LZ-15 - steel, 30x8mm, 1m LZ-3 - steel, 30x12mm, 1m LZ-5 - stainless steel, 30x10mm, 1m LZ-7 |
| Backup power supply | Keeps the gate operational in the event of a power failure. | - backup battery PS124 |
