NICE Run RUN1800 (F) sliding gate opener kit for gates up to 1800 kg/15 m
| Product availability: | In stock | We normally dispatch goods within 24 hours. |
|---|
in stock
€1,152.22 including VAT
| Weight |
|---|
| 30 kg |
Description of NICE Run RUN1800 (F) sliding gate opener kit for gates up to 1800 kg/15 m
NICE Run RUN1800 drive is designed for sliding gates weighing up to 1800 kg and a passage width of up to 15m. It has an electromechanical stop switch. The drive is non-reversible. Detailed technical specifications ». Download the manual ».
| Set NICE-RUN1800-F contains: | ||||
|---|---|---|---|---|
|
1 × | NICE Run RUN1800 drive | NICE-RUN1800-A | |
|
NICE Run RUN1800 electromechanical gate operator with RUA1 control unit, for gates weighing up to 1,800 kg and with a gate leaf length of up to 15 m.
|
Details
|
|||
|
1 × | NICE RUA1 control unit | NICE-RUA1 | |
|
Control unit for the NICE RUN drive |
Details
|
|||
|
1 × | NICE EPMB - Era Photocell Medium - photocells with BlueBUS connection | NICE-EPMB | |
|
Safety photocells are installed on either side of the opening. They create an infrared beam which, when interrupted by a car or pedestrian, for example, sends a signal to the drive to stop the gate or prevent it from opening. |
Details
|
|||
|
1 × | NICE ELDC LED Beacon with Antenna | NICE-ELDC | |
|
NICE LED ELDC flashing warning light made of impact-resistant polycarbonate with a built-in antenna for greater remote-control range (up to 150 m). |
Details
|
|||
|
1 × | NICE OXIBD remote control receiver | NICE-OXIBD | |
|
Radio signal receiver for remote controls. Supports two-way communication with selected remote control models. Range of up to 200m with an antenna. |
Details
|
|||
|
4 m | Rack with metal reinforcement | LZ-1-1 | |
|
A sliding gate with a fixed rack is moved by the drive gear via a rack-and-pinion mechanism. |
Details
|
|||
|
1 × | NICE MYGO4 - four-channel remote control | NICE-MYGO4 | |
|
NICE MYGO4 - four-channel remote control, rolling code, 433.92 MHz |
Details
|
|||
|
1 × | NICE Run RUN1800 Installation Manual |
Download
|
|
|
Installation manual with illustrated wiring diagrams and instructions for programming and pairing remote controls. |
||||
2 pcs. release keys
End stops
(Is this gate operator right for me?)
Compare with other gate operator kits:
| « Weaker kit | Alternative kit | Stronger kit » |
|---|---|---|
|
|
|
|
Gate operator features NICE RUN RUN1800
The gate operator is compact, safe and practical, making it ideal for both residential and commercial use. Impact-resistant cover, aluminium alloy housing with an epoxy coating.
The gate operator is suitable for automating sliding gates weighing up to 1,800 kg, with a gate leaf length of up to 15 m. These figures apply under the conditions specified by the manufacturer, such as weather conditions, temperature variations, gate rigidity and, above all, smooth gate movement. These conditions cannot always be met or controlled, so we recommend using the NICE Run RUN1800 gate operator for gates rated at 80% of these limits. See the Choosing a gate operator chapter for more information.
Highly user- friendly technology BlueBUS allows to power and control up to 7 pairs of photocells using a two-core cable.
The temperature sensor adjusts the gate operator's pulling force according to the climatic conditions. The gate operator also includes a thermal fuse.
Adjustable speed,, force and pause time for automatic gate closing and much more; see Programming.
Diagnostics using warning beacon.
The pinion module 4 is compatible with the rack in our range.
Run 1800 gate operator functions "The slave unit" automatically synchronises two motors. This means that two opposing sliding gates can be automated.
The NICE Run RUN1800 is an electromechanical gate operator suited to Slovakia's climate and complies with all European safety standards.
The RUN RUN1800 in pictures
| release mechanism | control unit | wiring diagram |
|---|---|---|
 |
 |
 |
| Instructions for releasing > |
Programming the gate operator > |
Detailed wiring diagram > |
You can find the detailed wiring diagram and more technical information on the NICE Run RUN1800 gate operator's own product page, or in the manual.
Gate operator technical specifications NICE RUN RUN1800
| Power supply | (Vac 50 Hz) | 230 |
| Power consumption | (VA) | 400W |
| Ingress protection rating | (IP) | 44 |
| Torque | (Nm) | 20 |
| Speed | (m/min) | 8.5–10.0 |
| Max. torque | (Nm) | 40 |
| Max. gate weight | (kg) | 1500 |
| Operating temperature | (°C) | -20 to +50 |
| Insulation class | 1 | |
| Gear module | 4 |
Complete technical specifications on the website of the NICE Run RUN1800 drive unit itself.
Accessories compatible with the NICE Run RUN1800 drive unit
We also recommend purchasing compatible optional accessories for the drive unit, or choosing one of the pre-assembled at a reduced price:
| What | Why | Type | Included? |
|---|---|---|---|
| Flashing warning light | The flashing warning light signals gate movement by flashing—ideal for exits with limited visibility. It also has a built-in antenna for greater remote-control range. | Yes, ELDC. | |
| Photocells | They detect obstacles while the gate is closing and stop its movement, preventing it from hitting cars or people. | - MoonBUS (MOFB, EPMB) | Yes, EPMB. |
| Transmitter |
For remote control of the gate. |
- MYGO4 - Era One (ON2E, ON4E) |
Yes, FLO2RE. |
| Receiver | Required for remote control of the gate. | - OXI - SMXI |
Yes, OXIBD. |
| Antenna | For greater remote-control range. | - built into the warning light LUCYB, MLBT - standalone ABFKIT antenna |
Built into the warning light. |
| Keypad | Useful if you forget your remote, or if many vehicles or people visit and you don't want to give everyone a remote or open the gate manually each time. | - MOTXR (wireless) | No. |
| Key switch | For operating the gate with a key via a switch connected to the drive unit by cable from any location. | - MOSE | No. |
| Rack | Required for the drive unit to automate the gate—without a rack, the drive unit cannot move the gate. | - nylon LZ-1 with steel reinforcement - steel LZ-2 |
Yes, 4x LZ-1 |
Manuals and documents for download
How can I order this item?
Choose the option that suits you:
- order online: use the buy button to add the goods to your shopping cart (you will find the buy button here in the product variants table).
- order by email: place your order at [email protected]
