NICE Run RUN1800 (C) sliding gate operator kit up to 1800 kg/15 m
| Product availability: | In stock | We normally dispatch goods within 24 hours. |
|---|
in stock
€1,056.49 including VAT
| Weight |
|---|
| 23 kg |
Description of NICE Run RUN1800 (C) sliding gate operator kit up to 1800 kg/15 m
NICE Run RUN1800 drive is designed for sliding gates with a weight up to 1800 kg and a passage width up to 15 m. It has an electromechanical stop switch. The drive is non-reversible. Detailed technical specifications ». Download the manual ».
| Set NICE-RUN1800-C contains: | ||||
|---|---|---|---|---|
|
1 × | NICE Run RUN1800 drive | NICE-RUN1800-A | |
|
NICE Run RUN1800 electromechanical gate operator with RUA1 control unit, for gates weighing up to 1,800 kg and with a gate leaf length of up to 15 m.
|
Details
|
|||
|
1 × | NICE RUA1 control unit | NICE-RUA1 | |
|
Control unit for the NICE RUN drive |
Details
|
|||
|
1 × | NICE OXIBD remote control receiver | NICE-OXIBD | |
|
Radio signal receiver for remote controls. Supports two-way communication with selected remote control models. Range of up to 200m with an antenna. |
Details
|
|||
|
1 × | NICE EPMB - Era Photocell Medium - photocells with BlueBUS connection | NICE-EPMB | |
|
Safety photocells are installed on either side of the opening. They create an infrared beam which, when interrupted by a car or pedestrian, for example, sends a signal to the drive to stop the gate or prevent it from opening. |
Details
|
|||
|
1 × | NICE MYGO4 - four-channel remote control | NICE-MYGO4 | |
|
NICE MYGO4 - four-channel remote control, rolling code, 433.92 MHz |
Details
|
|||
|
1 × | Installation Manual |
Download
|
|
|
Installation manual with illustrated wiring diagrams and instructions for programming and pairing remote controls. |
||||
2 pcs. release keys
End stops
(Is this gate opener right for me?)
Compare with other gate opener kits:
| « Weaker kit | Alternative kit | Stronger kit » |
|---|---|---|
|
|
|
|
Gate opener features NICE RUN RUN1800
The gate opener is compact, safe and practical, making it ideal for both residential and commercial use. Impact-resistant cover, with an epoxy-coated aluminium alloy body.
The gate opener is suitable for automating a sliding gate weighing up to 1800 kg, with a gate leaf length of up to 15 m. These values apply under the conditions specified by the manufacturer, including weather conditions, temperature variations, gate rigidity and, above all, smooth gate movement. These conditions cannot always be achieved or controlled, so we recommend using the NICE Run RUN1800 gate opener ideally for gates operating at 80% of these limits. See the Choosing a gate opener section for more information.
Very user- friendly BlueBUS allows you to power and control up to 7 pairs of photocells using a two-core cable.
The temperature sensor adjusts the gate opener's pulling force according to the weather conditions. The gate opener also includes a thermal fuse.
Adjustable speed,, force and pause time for automatic gate closing, and much more; see Programming.
Diagnostics using warning beacon.
The gear module 4 is compatible with the rack available in our range.
Run 1800 gate opener functions "The slave unit" ensures automatic synchronisation of two motors. This means that two sliding gates moving towards each other can be automated.
The NICE Run RUN1800 is an electromechanical gate opener suited to Slovakia's climate and compliant with all European safety standards.
The RUN RUN1800 in pictures
| manual release | control unit | wiring diagram |
|---|---|---|
 |
 |
 |
| Instructions for manual release > |
Programming the gate opener > |
Detailed wiring diagram > |
You can find the detailed wiring diagram and other technical information on the NICE Run RUN1800 gate opener product page, or in the manual.
Gate opener technical specifications NICE RUN RUN1800
| Power supply | (Vac 50 Hz) | 230 |
| Power consumption | (VA) | 400W |
| Protection rating | (IP) | 44 |
| Torque | (Nm) | 20 |
| Speed | (m/min) | 8.5-10.0 |
| Max. torque | (Nm) | 40 |
| Max. gate weight | (kg) | 1500 |
| Operating temperature | (°C) | -20 to +50 |
| Insulation class | 1 | |
| Gear module | 4 |
Complete technical specifications on the page for the NICE Run RUN1800 drive unit itself.
Accessories compatible with the NICE Run RUN1800 drive unit
We also recommend purchasing compatible optional accessories for the drive unit, or choosing one of the pre-assembled discounted sets:
| What | Why | Type | In the set? |
|---|---|---|---|
| Flashing beacon | The flashing beacon indicates gate movement by flashing—useful at exits with poor visibility. It also has a built-in antenna for increased remote-control range. | - Lucy (LUCYB) - Moonlight (MLTB, ELB) |
No. |
| Photo cells | They detect an obstacle while closing and stop the gate—so it won't hit a car or anyone. | - MoonBUS (MOFB,EPMB) | Yes, EPMB. |
| Transmitter |
For remote control of the gate. |
- MYGO4 - Era One (ON2E, ON4E) |
Yes, Flo2RE. |
| Receiver | Required for remote control of the gate. | - OXI - SMXI |
Yes, OXIBD. |
| Antenna | For improved remote-control range. | - built into the flashing beacon LUCYB, MLBT - ABFKIT antenna only |
No. |
| Keypad | Useful if you forget your remote, have a lot of vehicles or people coming and going and don't want to give everyone a remote, or if you don't want to open the gate manually. | - MOTXR (wireless) | No. |
| Key switch | For operating the gate with a key via a switch wired to the drive unit from any location. | - MOSE | No. |
| Rack | Required for the drive unit to operate—the motor needs a rack to move the gate. | - nylon LZ-1 with steel reinforcement - steel LZ-2 |
No. |
Manuals and documents for download
