Components used:
2x V-02-3 Adjustable swing trolley, 5 rollers with mounting plate
6m CP-ZN-70 C-profile 70x70x4 mm, Zn – hot-dip galvanised
SN-1-70 Bottom guide roller – galvanised, for 70x70x4mm C-profile
DK-1-70 End stop receiver – narrow, for 70x70 profile
VVR-3-G Top guide with two adjustable rubber-coated rollers
SK-1-70 End cap for a cantilever gate C-profile – galvanised, 70x70
NICE-RB400-D Drive kit for sliding gates up to 400kg/7m, NICE Robus RB400 (D)
4m LZ-1-1 Plastic-coated rack 30x20mm, with 12x12mm steel core, M4
4x PR-2-16-A Adjustable screw-on hinge with lock nut – narrow plate
KLN-NG-01-L Straight handle + fixed knob, brushed stainless steel – 1 pair, left
KLN-NG-01-P Straight handle, brushed stainless steel, 1 pair, right
KLN-84 Sharp-edged straight handle in brushed stainless steel with oval rose
1KLN-S1 Oval escutcheon for a cylinder, in brushed stainless steel
2x P376-16 Adjustable weld-on hinge with sleeve
UB-1-40G Top gate stop with rollers
ZK-03 + ZE-05 Universal left/right electric-lock strike box + electric lock 6-14V (AC/DC), ZK-03
2x ZK-05 Universal right/left gate stop
2x PLS-07 Universal plate with holes, 150x150mm, 10mm thick
4x P255-060 Weld-on hinge with lugs, 60x10mm, and steel/bronze washer
4x P255-040 Weld-on hinge with lugs, 40x10mm, and steel/bronze washer
11x6m JOKL-100x20x1,2-ZN Galvanised rectangular hollow section, 100x20x1,2 mm
3x6m U-PROFIL-20x25x20-ZN U-profile 20x25x20x2mm, galvanised
3x NICE-ON3EBD NICE Era One BD ON3EBD – three-channel, two-way remote control
3x KZK642 60x40x1,5 mm profile with lock, profile length 2 m
UD-ZN-1 Zinc-plated bracket for fixing the bottom and top gate stops.
