Aluminum fence slat 80x16 mm, rectangular profile, anthracite RAL7016, smooth surface
NEW| Product availability: | In stock | We normally dispatch goods within 24 hours. |
|---|
in stock
€82.60 including VAT
| Length [m] | Weight |
|---|---|
| 6m +/- 5mm | 4,41 kg |
in stock
€41.30 including VAT
| Length [m] | Weight |
|---|---|
| 3m +/- 5mm | 2,21 kg |
in stock
€27.53 including VAT
| Length [m] | Weight |
|---|---|
| 2m +/- 5mm | 1,47 kg |
Description of Aluminum fence slat 80x16 mm, rectangular profile, anthracite RAL7016, smooth surface
Aluminium slat, with a finish in anthracite, can be used as infill for a fence, gate, or any other area. The slat has a rectangular shape with a height of 80 mm and a width of 16 mm, and is available in lengths of 2m, 3m, or 6m.
Example of a pedestrian gate and driveway gate made from anthracite aluminium slats:
The slat is hollow and on the inside of the sides has guide grooves for the fixing screws. The simplest way to install them is using fixing profiles with pre-routed grooves for accurate drilling and screw fixing.
RECTANGULAR ALUMINIUM SLAT PATTERNS:
Combined with a fixing profile you can create a vertical pattern:
 |
 |
Depending on the desired effect, aluminium slats of different heights can also be alternated. Our range also includes a 20mm-high rectangular slat without a finish, or an anodised slat, both ideal for creating modern patterns.
Example of an opaque slat infill pattern and an open pattern:
INSTALLATION METHODS FOR RECTANGULAR ALUMINIUM FENCE SLATS:
Method for fixing the slats vertically in a U-channel (width 20.5mm):
 |
 |
The slats can also be installed vertically using end caps, which are inserted into the slat from above.
FINISH:
Aluminium is generally an excellent material with good resistance to corrosion and weather, and a long service life. The slat is made from EN AW-6060 T66 aluminium and supplied with an anthracite RAL 7016 finish.
The profile is finished with a smooth powder coating. After application, the powder coating is cured in an oven. This finish offers a long service life and resistance to UV radiation and yellowing. It is intended for use in construction, where lasting colour and gloss are essential.
Note
The manufacturing process requires at the ends of profiles with a powder-coated finish approximately 1 cm of the profile at each end to be left for holding during coating. There is a small hole at the end of the profile, which should be taken into account. If necessary, the end can easily be cut off or concealed inside the fixing profile.
Realistic photo of the anthracite slat:
Difference between a smooth finish and a textured finish:
Textured anthracite Anthracite with a smooth finish
SUITABLE FIXING SCREWS:
Screws with countersunk heads DIN 7982 3.5x19 mm
TECHNICAL SPECIFICATIONS OF THE ALUMINIUM SLAT FOR GATE AND FENCE INFILL:
Material: natural aluminium (EN AW-6060 T66)
Finish: Anthracite – smooth finish
Dimensions: 80x16 mm
Length: 2 000 mm, 3 000 mm, 6 000 mm
Weight: 1.470 kg, 2 205 kg, 4.022 kg
