Components used:
6m CP-70 - C-profile 70x70x4 mm, Fe
2x V-02-3 - Pivoting trolley with adjustment, 5 rollers with mounting plate
SN-1-70 - Bottom guide roller - galvanized, 70x70
DK-1-70 - End stop receiver - narrow, for 70x70 profile
VVR-3-G-300 - Extended top guide with two adjustable rubber-coated rollers
SK-1-70 - Cover cap for cantilever gate C-profile - galvanized, 70x70
UB-1-40G - Top gate stop with rollers
2x CAIS-PARK-CSM - CAIS Universal holder for stops, 175mm PARK CSM
NICE-RB600-E - Drive kit for sliding gates up to 600kg/8m NICE Robus RB600 (E)
1m LZ-1-1 - Plastic-coated rack, 30x20mm, with 12x12mm steel core, M4
NICE-ABF - NICE Aerial ABF - adjustable external drive antenna with mounting plate and 3m cable
5x PLS-01 - Universal mounting plate with holes, 120x120mm, 8mm thick
13x PLS-05 - Universal mounting plate with holes, 100x100mm, 10mm thick
7x PLS-07 - Universal mounting plate with holes, 150x150mm, 10mm thick
6x P375-20 - Adjustable weld-on hinge with locknut
150x DP-10 - Weld-on anchor for fence infill panels, 35x30x4 mm
6m JOKL-80x40x2 - Rectangular hollow section 80x40x2, black
27m JOKL-60x40x2 - Rectangular hollow section 60x40x2, black
6m JOKL-100x100x3 - Rectangular hollow section 100x100x3, black
18m JOKL-40x40x3 - Rectangular hollow section 40x40x3, black
12m J-L20x20x3 - L-shaped steel bar 20x20x3 (L-section), untreated
ZO-28 - Rectangular end cap
3x PS-SO-13 - Sheet-metal cap, square, bent, Fe
